Description
Omnetics Micro-D HDMI connectors are designed to meet HDMI specifications while using standard Omnetics parts. Using both simulation and measurement, performance was maximized through a carefully designed signal pinout. This provides excellent crosstalk and impedance performance and yields maximum data transmission that meets the requirements, per the HDMI specification.
Features
Omnetics Micro-D HDMI connectors are designed to meet HDMI specifications while using standard Omnetics parts. Using both simulation and measurement, performance was maximized through a carefully designed signal pinout. This provides excellent crosstalk and impedance performance and yields maximum data transmission that meets the requirements, per the HDMI specification.
